ALUMINIUM & GLASS FACADE

Our Technology

Our specialist knowledge and high-performance technology solutions we provide a first-class service being able to support the construction process from the very first sketch to handing over the building. Whatever the architecture line, the range of the equipment’s and technology used by our company will offer the right answer to all design questions.

  • CNC MILLING MACHINE
  • ELUMATEC 5-AXIS MODEL SBZ-151 CNC ALUMINUM MACHINING CENTER
  • ELUMATEC DOUBLE MITRE SAW DG 244
  • ELUMATEC EP 124 CORNER CRIMPER
  • HARRISON ALPHA 460 PLUS CNC CENTRE LATHE
  • C.M.R CNC RADIAL DRILL
  • JORNS A.G BENDING MACHINE
  • TEKNA TK 419 CNC MILLING CENTER
  • TEKNA TK 427 3-AXIS CNC MACHINING CENTER
  • WICONA MULTIFUNCTION PNEUMATIC PUNCHING TOOL
  • CBC 50 TON METAL BENDING MACHINE

Industrial machines providing
high-quality services

ALUMINIUM MACHINES

ELUMATEC 5-AXIS

ELUMATEC 5-AXIS MODEL SBZ-151 CNC ALUMINUM MACHINING CENTER.

Latest generation of Elumatec technologies with a 5-axis profile machining center and 6-sided machining. Designed for a flexible and efficient machining of aluminum and thin-walled steel profiles.



All operations, such as routing, drilling, tapping, thread milling, notching and sawing, are performed while the profile bar is stationary to protect the profile surfaces.

  • 5-AXIS PROFILE MACHINING CENTRE
  • 6-SIDED MACHINING
  • FAST POSITIONING
  • AUTONOMOUS CLAMP POSITIONING
  • REMOTE ONLINE MAINTENANCE

ELUMATEC DOUBLE MITRE SAW

ELUMATEC DOUBLE MITRE SAW DG 244.

The reliable Elumatec principle of ‘Cutting from below’. It provides external dimension cuts at all angle positions, which requires no length calculations when cutting profiles of different heights.



The universal pivoting and tilting of both saw units allows cutting of high and wide profiles as well as every type of compound mitre cut. With cutting length variance of  4,500 mm, 6,000 mm  and 7,500 mm

  • HYDRO-PNEUMATIC SAW FEED
  • SAW FEED – MINIMUM CUTTING LENGTH 400 MM
  • HIGH PERFORMANCE CUTTING FLUID
  • PROFILE LIFTING BARS
  • TRANSOM STOP AND LEAD-CUT STOP

ELUMATEC CORNER CRIMPER

ELUMATEC EP 124 CORNER CRIMPER.

A machinery designed for an efficient pressing of aluminum profiles with large dimensions. It is easy to adjust and operate and has short changeover times thanks to a simple blade-changing system.



Due to large-volume bellows cylinders this machine provides extremely high pressing force. It allows pressing of frames with an inner dimension starting at 150 mm with retractable, hydro-pneumatically controlled counter bearing.

  • EXTREMELY HIGH PRESSING FORCE
  • LENGTH 1,100 MM, DEPTH 950 MM
  • PRESSING HEIGHT 140 MM
  • PNEUMATIC DRIVE

TEKNA MILLING CENTER

TEKNA TK 419 CNC MILLING CENTER.

A compact machine with remarkable capacity to work. This machine is characterized by vacuum beds to work sheets of aluminum, composite, HPL, wood, etc. It contains a 3-axis CNC vertical machining center with superior machining capability in Y (1600 mm), X(3200mm) and Z(100 mm).



It features a clamping system made up of vacuum tables that allow panels and plates to be held by vacuum; this solution is useful to obtain an extremely efficient machining of thin components that could hardly be fixed by means of a traditional clamping system.

  • COOLING SYSTEM
  • 0,1 MM ACCURACY
  • ROTATION SPEED OF 18000 RPM
  • PROCESSES ALL ALUMINUM PANELS​​​​​​​

WICONA PUNCHING TOOL

WICONA MULTIFUNCTION PNEUMATIC PUNCHING TOOL.

The Multifunction Pneumatic Punching Tool can be used in a flexible manner thanks to the variety of interchangeable tools. It offers a six-piece tool kit provides you with up to 14 processing options. This covers all the work involved in producing a window.



It offers 14 ways of processing using one tool arrangement (for all construction depths), e.g: Corner joint frame , Butt-joint transom, Corner joint sash, Drainage frame, Drainage sash, Slide rod machining (cutting to length, punching, piercing), Handle hole punching

  • MULTI FUNCTION PUNCH
  • HAND PUNCHES
  • CRAMPING TOOLS
  • DRILL TEMPLATES FOR SPECIAL APPLICATIONS
  • INJECTION PISTOLS

JORNS BENDING & CUTTING MACHINE

JORNS A.G BENDING AND CUTTING MACHINE.

The semi-automatic Jorns bending and cutting machine configured in lengths of 6 meters and with a bending capacity for aluminum sheet up to 3 mm. It offers a great deal of freedom – and not only when it comes to the clamping tool.



The use of this technology and the stop fingers that can be moved freely on the sides guarantee maximum precision and flexibility to bend aluminum sheets.

  • HIGH ACCURACY
  • INTUITIVE GRAPHIC PROGRAMMING
  • THE HIGH LEVEL OF ANGULAR ACCURACY

METAL MACHINES

CNC MILLING MACHINE

CNC MILLING MACHINE.

The economical alternative for high volume machining. All movement is done by the workpiece. All required process tools are arranged inside the machining area at a fixed position. All workpieces are melted on a moving fixture and can therefore translate in 3-axes.



Spindle and tool form a functional unit. Each tool has its own specific, optimized spindle size and drive by using multi spindle heads or turrets. The worktable with clamped workpiece(s) moves from tool to tool; shortest chip-to-chip times.

  • NO TOOL CHANGE WITHIN THE PROCESS
  • NO INACCURACY DUE TO TOOL CHANGE.
  • SINGLE/MULTIPLE PART CLAMPING
  • SINGLE/MULTIPLE SPINDLE MACHINING​​​​​​​

HARRISON CNC CENTRE LATHE

HARRISON ALPHA 460 PLUS CNC CENTRE LATHE.

Harrison Alpha 460 Plus Gap Bed with 460mm swing x 1000mm between centers. It contains a Spindle bore of 76mm. 20 – 2000 rpm Spindler speed (3 ranges).



Equipped with Harrison/Fanuc GE Operator panel and screen. Very popular CNC Lathe.

  • 3 JAW CHUCK
  • QUICK CHANGE TOOL POST AND 4 OFF TOOLHOLDERS
  • HARRISON/FANUC GE OPERATOR PANEL AND SCREEN
  • STATIONARY STEADY
  • GUARDING
  • LIGHTING
  • COOLANT SYSTEM

TEKNA CNC MACHINING CENTER

TEKNA TK 427, 3-AXIS CNC MACHINING CENTER.

Structure robustness and high stability of all components of this machining center allow the TK 427 model to be used not only to perform machining operations on light alloys and similar materials but also on materials that require higher performances. The peculiarities of the machine assure an excellent superficial finishing and a better machining accuracy.



This machining center is designed for drilling and conventional milling processes and also for copy-milling operations on aluminum extruded profiles and other materials, including steel profiles up to 10 mm thickness, steel reinforced PVC, and various other plastics or wood

  • HIGH STABILITY
  • HIGH PERFORMANCES
  • HIGH ACCURACY
  • DRILLING PROCESSES
  • MILLING PROCESSES​​​​​​​

C.M.R CNC RADIAL DRILL

C.M.R CNC RADIAL DRILL.

CNC Radial drilling machine CMR model KR 65 x 2000 arm length complete with: coolant system fixed cube standard accessories

  • HIGH ROTATION SPEED
  • HIGH PRECISION DRILLING
  • PNEUMATIC DRIVE​​​​​​​

CBC 50 TON METAL BENDING MACHINE

CBC 50 TON METAL BENDING MACHINE.

This bending machine is the perfect answer in terms of reliability, high-performance and productivity for iron and steel systems.



The structure ensures high quality, and the state-of-the-art electronic solutions guarantee maximum flexibility with Hydraulic CNC bending machine 3500 mm length,  110 mm thickness up to 50 ton compressive strength.

  • EASY TO USE CONTROL UNIT
  • STABILE BODY STRUCTURE
  • PERFECT DESIGN
  • DIFFERENT TOOL USAGE OPTIONS
  • MAXIMUM SAFETY STANDARDS​​​​​​​
